工商业储能逆变器
艾罗能源工商业储能逆变器是一款专为商业和工业场景设计的高性能解决方案
概述
艾罗能源工商业储能逆变器可无缝对接光伏系统，提供卓越的能效管理与先进技术特性，助力企业有效降低用能成本、优化碳足迹，是工商业清洁能源转型的理想选择。
-
卓越性能
艾罗能源工商业储能逆变器具备200%光伏超配能力与强劲输出性能。无论您是扩展光伏容量还是在复杂工况下运行，该逆变器都能保障系统始终保持高效运行。
-
最高可达200%
光伏超配能力
-
最高可达160A
充放电电流
-
-
稳定可靠
IP66防护等级与电池端子温度监测等保护功能，确保逆变器在多种环境下稳定运行。交直流侧均配备II级浪涌保护装置，有效防御电网冲击与电气故障。
-
最高可达200%
EPS输出功率
-
<10ms
UPS切换时间
-
IP66
防护等级
-
-
智能管理
艾罗能源工商业储能逆变器具备AI能源预测与虚拟电厂（VPP）就绪能力，完美兼容热泵、电动汽车充电桩等智能家居设备，支持微电网系统集成。
-
AI能源预测就绪
-
虚拟电厂（VPP）就绪
-
微电网兼容
-
产品参数
-
X3-ULT-15K-
PV INPUT
Max. recommended PV array power 30 kWp MPPT voltage range 160~950 V No. of MPP. trackers / strings per MPPT 2 / (2 / 2) Max. input current per MPPT 36 A / 36 A -
AC INPUT & OUTPUT (ON-GRID)
Rated output power 15000 W(AS4777 14999 W) Rated AC voltage 3/N/PE,220/380V
3/N/PE,230/400V
-
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Peak EPS output power 2 times of rated power, 10 s Switchover time <10 ms -
GENERAL
Ingress protection IP66 Dimensions (W /H / D) 696x526x240 mm Net Weight 47 kg
-
-
X3-ULT-15KP
-
PV INPUT
Max. recommended PV array power 30 kWp MPPT voltage range 160~950 V No. of MPP. trackers / strings per MPPT 3 / (2 / 2 / 2) Max. input current per MPPT 36 A / 36 A / 36 A -
AC INPUT & OUTPUT (ON-GRID)
Rated output power 15000 W(AS4777 14999 W) Rated AC voltage 3/N/PE,220/380V
3/N/PE,230/400V
-
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Peak EPS output power 2 times of rated power, 10 s Switchover time <10 ms -
GENERAL
Ingress protection IP66 Dimensions (W /H / D) 696x526x240 mm Net Weight 47 kg
-
-
X3-ULT-19.9K
-
PV INPUT
Max. recommended PV array power 40 kWp MPPT voltage range 160~950 V No. of MPP. trackers / strings per MPPT 2 / (2 / 2) Max. input current per MPPT 36 A / 36 A -
AC INPUT & OUTPUT (ON-GRID)
Rated output power 20000 W Rated AC voltage 3/N/PE,220/380V
3/N/PE,230/400V
-
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Peak EPS output power 2 times of rated power, 10 s Switchover time <10 ms -
GENERAL
Ingress protection IP66 Dimensions (W /H / D) 696x526x240 mm Net Weight 47 kg
-
-
X3-ULT-20K
-
PV INPUT
Max. recommended PV array power 40 kWp MPPT voltage range 160~950 V No. of MPP. trackers / strings per MPPT 2 / (2 / 2) Max. input current per MPPT 36 A / 36 A -
AC INPUT & OUTPUT (ON-GRID)
Rated output power 20000 W Rated AC voltage 3/N/PE,220/380V
3/N/PE,230/400V
-
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Peak EPS output power 2 times of rated power, 10 s Switchover time <10 ms -
GENERAL
Ingress protection IP66 Dimensions (W /H / D) 696x526x240 mm Net Weight 47 kg
-
-
X3-ULT-20KP
-
PV INPUT
Max. recommended PV array power 40 kWp MPPT voltage range 160~950 V No. of MPP. trackers / strings per MPPT 3/ (2 / 2 / 2) Max. input current per MPPT 36 A / 36 A / 36 A -
AC INPUT & OUTPUT (ON-GRID)
Rated output power 20000 W Rated AC voltage 3/N/PE,220/380V
3/N/PE,230/400V
-
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Peak EPS output power 2 times of rated power, 10 s Switchover time <10 ms -
GENERAL
Ingress protection IP66 Dimensions (W /H / D) 696x526x240 mm Net Weight 47 kg
-
-
X3-ULT-25K
-
PV INPUT
Max. recommended PV array power 50 kWp MPPT voltage range 160~950 V No. of MPP. trackers / strings per MPPT 3 / (2 / 2 / 2) Max. input current per MPPT 36 A / 36 A / 36 A -
AC INPUT & OUTPUT (ON-GRID)
Rated output power 25000 W(VDE4105 24900 W) Rated AC voltage 3/N/PE,220/380V
3/N/PE,230/400V
-
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Peak EPS output power 2 times of rated power, 10 s Switchover time <10 ms -
GENERAL
Ingress protection IP66 Dimensions (W /H / D) 696x526x240 mm Net Weight 47 kg
-
-
X3-ULT-30K
-
PV INPUT
Max. recommended PV array power 60 kWp MPPT voltage range 160~950 V No. of MPP. trackers / strings per MPPT 3 / (2 / 2 / 2) Max. input current per MPPT 36 A / 36 A / 36 A -
AC INPUT & OUTPUT (ON-GRID)
Rated output power 30000 W (AS4777 29999 W,VDE4105 29900 W) Rated AC voltage 3/N/PE,220/380V
3/N/PE,230/400V
-
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Peak EPS output power 2 times of rated power, 10 s Switchover time <10 ms -
GENERAL
Ingress protection IP66 Dimensions (W /H / D) 696x526x240 mm Net Weight 47 kg
-
